SLHY single shaft paddle feed mixer

This mixer have two screws, that working with one shaft, giving short mixing cycle (3 minutes) and high mixing homogeneity

Skype
Introduction Inquiry
1.1This horizontal ribbon mixer is characterized with simple and reasonable structure, easy maintenance, low power, safe reliability, high mixing evenness, without residual, excellent tightness etc.

1.2. Screw mixer mixing time is short , the mixing evenness degree is high( cv ≤7%).

1.3.This mixer have two screws, that working with one shaft, giving short mixing cycle (3 minutes) and high mixing homogeneity;

1.4.U type structure ensures the low resistive exercise of the mixing material (powder, semiliquid ) in the cylinder body of small resistance movement.

1.5.Widely used in poultry, animal feed, livestock plants, chemical, food and flour industries, etc.

Main Technical Parameters of horizontal ribbon mixer

MODEL

SLHY50

SLHY0100

SLHY150

SLHY250

SLHY500

SLHY1000

CAPACIT(kg/batch)

  50

 100

 150

  250

  500

 1000

 Power(kw)

  1.5

 1.5

 1.5

2.2

  7.5

  15

Dimension(L*W*H)

1300*500*

1000mm

1600*600*

1100mm

1900*700*

1200mm

2200*800*

1300mm

2200*1000*

1950mm

2600*1100*

2100mm

Mix Evenness Degree

 CV1-7%

 CV1-7%

 CV1-7%

 CV1-7%

   CV1-7%

 CV1-7%

Mix Time (min)

 3-6

 3-6

 3-6

 3-6

 3-6

 3-6
