SFSP Feed Hammer Mill Grinder from hengfu machinery
Author:Animall Feed Blok Making Machine updatetime:2019-01-18 15:49 Clicks:

SFSP Feed Hammer Mill Grinder from hengfu machinery:

The main function of the feed mill is used to crush all kinds of fodder (such as maize, sorghum) and fodder (such as bran crustaceans, stem and vine type, etc.). Hammer mill feed formulation form joint design series in 1975, and the development of standards. Hammer mill is now used more, higher electricity yield, crushing a better model.


Model SFSP56*36 SFSP56*40 SFSP708*40
Rotor diameter(mm) 560mm 560mm 708mm
Crush room width(mm) 360mm 400mm 400mm
Rotate Speed(r/min) 2900 2900 2900
Number of Hammers 40 40 40
Capacity(t/h) 1-3 2-5 3-8
Main Power(kw) 22 37 55
Weight(kg) 800 920 1600
Dimension(L*W*H) 1430*700*1000mm 1500*700*1000mm 1850*750*1250mm


The hammer mill is commonly used within the structure of hammer, grinding chamber structure was water drop, after its feed from the mill to the top of the feed hopper into the crushing chamber material to be crushed. The design of the belt drive gear motor through V-belt pulley driven spindle running turn the rotor rotates. Meanwhile, the hammer striking the material feed medium may be pulverized feed eventually crumbled into small crumb.

 SFSP Feed Hammer Mill Grinder from hengfu machinery

The main part of the design is to design gearing,compared to a variety of gear, the eventual adoption of V belt drive,because the V-belt has good flexibility,and the belt drive can be buffered,vibration absorption。 A motor driven belt running,the spindle is rotated at a constant speed and drive the hammer rotor and the rotor to rotate on the spindle。High-speed rotating hammer to feed  into the crushing chamber were hit,and eventually rupture。Screen crushed beneath the feed by filtering to obtain pulverized feed grains, the end of the entire grinding process.
